НАСОС ГИДРАВЛИЧЕСКИЙ ГИДРОНАСОС НАСОСНАЯ УСТАНОВКА СТАНЦИЯ PUMP
04 1019802009 齿轮泵，Gear Pump 1
011 1019802010 活塞组件，Piston Ass'y 2
013 1019802011 汽缸（R）组件，Cylinder (R) Ass'y 1
014 1019802012 汽缸（L）组件，Cylinder (L) Ass'y 1
030 1019802013 斜板组件，Swash Plate Ass'y 2
041 1019800960 单向阀1组件，Check Valve 1 Ass'y 2
043 1019802014 单向阀2组件，Check Valve 2 Ass'y 2
080 1019801045 电磁比例减压阀总成，Relief Valve 1
111 1019802015 驱动轴（F），Drive Shaft (F) 1
113 1019802016 驱动轴（R），Drive Shaft (R) 1
114 1019802017 方栓活接管， Spline Coupling 1
123 1019802018 滚动轴承，Anti-resistance Bearing 2
124 1019802019 滚动轴承，Anti-resistance Bearing 2
127 1019802020 支撑垫片，Supporting Spacer 3
141 1019802021 汽缸体，Cylinder Body 2
151 1019802022 活塞，Piston 18
152 1019802023 鞋形尾撑，Shoe 18
153 1019802024 压板，Plate 2
156 1019802025 球面套管，Spherical Bush 2
157 1019802026 汽缸弹簧，Cylinder Spring 18
211 1019802027 支撑板，Plate 2
212 1019802028 斜板，Swash Plate 2
214 1019802029 倾转套管，Tilting Bush 2
251 1019802030 斜板支撑台，Support 2
261 1019802031 密封盖板(F)，Seal Cover (F) 1
271 1019802032 泵壳，Pump Casing 2
312 1019802033 阀体，Valve Body 1
313 1019802034 阀盘（R），Valve Plate (R) 1
314 1019802035 阀盘（L），Valve Plate (L) 1
401 1019802036 内六角螺 M20×23，Screw 8
406 1019801317 内六角螺钉，Hex. Screw 4
466 1019801330 Vp螺栓，Bolt 2
468 1019801331 Vp螺栓，Bolt 4
490 1019801339 预埋栓，Bolt 18
530 1019802037 倾斜销组件，Tilting Pin Ass'y 2
531 1019802038 倾斜销，Tilting Pin 2
532 1019802039 伺服活塞，Servo Piston 2
534 1019802040 止动销(L)，Stop pin (L) 2
535 1019802041 挡板（S），Retainer Plate (S) 2
541 1019801046 底座，Seat 4
543 1019801047 止动销1，Stop pin 1 2
544 1019802042 止动销2，Stop pin 2 2
545 1019801270 钢球，Steel Ball 4
548 1019800962 反馈销，Pin 2
702 1019802043 O型密封环，O-Ring 2
710 1019802044 O型密封环，O-Ring 1
717 1019802045 O型密封环，O-Ring 2
719 1019802046 O型密封环，O-Ring 2
724 1019801300 O型密封环，O-Ring 16
725 1019801286 O型密封环，O-Ring 4
728 1019801297 O型密封环，O-Ring 4
732 1019802047 O型密封环，O-Ring 2
774 1019802048 油封，Oil Seal 1
789 1019802049 垫圈，Washer 2
792 1019802050 垫圈，Washer 2
808 1019801303 六角螺母，Nut 4
824 1019802051 挡环，Retainer Ring 2
885 1019802052 阀盘销，Pin 2
886 1019801323 弹簧销，Pin 4
901 1019802053 有眼螺栓，Bolt 2
953 1019802054 内六角固定螺丝，Screw 2
954 1019802055 固定螺丝，Screw 2
981 1019802056 铭牌，Name Plate 1
983 1019801321 销子，Pin 2
412 1019801802 内六角有孔螺钉，Screw 2
413 1019801801 内六角有孔螺钉，Screw 2
436 1019801800 内六角有孔螺钉，Screw 2
438 1019801799 内六角有孔螺钉，Screw 10
496 1019801339 预埋拴，Bolt 5
601 1019800921 壳体，Casing 1
611 1019802057 反馈杆，Feedback Rod 1
612 1019800932 连杆(1)，Lever(1) 1
613 1019800933 连杆(2)，Lever(2) 1
614 1019800934 支座销，Pin 1
615 1019800935 调整柱，Adjusting Plunger 1
621 1019800936 补偿活塞，Compensating Piston 1
622 1019800937 活塞套，Piston Bush 1
623 1019801044 补偿杆，Compensating Rod 1
624 1019801022 弹簧(C)，Spring (C) 1
625 1019802058 外部弹簧，Outer Spring 1
626 1019800939 内部弹簧，Inner Spring 1
627 1019801049 伸缩杆©，Adjusting Stem (C) 1
628 1019801025 调整螺钉(C)，Adjusting Screw (C) 1
629 1019800927 罩(C)，Cover (C) 1
630 1019800940 锁紧螺母，Lock Nut 1
631 1019802059 Pf套筒，Pf Sleeve 1
641 1019800930 导向罩，Guide Housing 1
643 1019801040 导向活塞，Guide Piston 1
644 1019801023 弹簧(Q)，Spring (Q) 1
645 1019801050 调节圈(Q)，Adjusting Ring (Q) 1
646 1019800951 导向弹簧，Pilot Spring 1
651 1019800929 套筒，Sleeve 1
652 1019800941 滑阀，Slide Valve 1
653 1019800942 弹簧，Spring 1
654 1019800944 复位弹簧，Return Spring 1
655 1019800943 调节弹簧，Adjusting Spring 1
656 1019800958 盲板，Blind Plate 1
708 1019801281 O型密封环，O-Ring 1
725 1019801284 O型密封环，O-Ring 1
728 1019801292 O型密封环，O-Ring 1
730 1019801295 O型密封环，O-Ring 1
732 1019801290 O型密封环，O-Ring 1
733 1019801293 O型密封环，O-Ring 1
734 1019801276 O型密封环，O-Ring 1
735 1019801287 O型密封环，O-Ring 1
753 1019801301 O型密封环，O-Ring 1
755 1019801286 O型密封环，O-Ring 2
756 1019801298 O型密封环，O-Ring 1
763 1019801279 O型密封环，O-Ring 1
801 1019801304 六角螺母，Nut 1 JISB1181 RN-M8
802 1019801029 六角螺母 M10，Nut 1
814 1019801324 阻止环，Snap Ring 1 JISB2804 SR-10
836 1019801376 挡圈，Retainer Ring 1
858 1019801309 锁紧环，Lock Ring 2 JISB2804 RR-15
874 1019801346 销，Pin 1
875 1019801345 销，Pin 2
876 1019801347 销，Pin 2
887 1019800950 销，Pin 1
897 1019801348 销，Pin 1
898 1019802060 销，Pin 1
924 1019801362 内六角锁紧螺钉，Lock Screw 1
