НАСОС ГИДРАВЛИЧЕСКИЙ ГИДРОНАСОС SUNWARD | 730201000127

ГЛАВНЫЙ МАСЛЯНЫЙ PUMP ОСНОВНОЙ  НАСОСНАЯ СТАНЦИЯ ГИДРАВЛИЧЕСКАЯ ГИДРОМОТОР МОТОР ГИДРАВЛИЧЕСКИЙ ДЛЯ ЭКСКАВАТОРА САНВАРД

730201000127 1 MAIN PUMP ◎主泵1
730201000205 1 本体1
111 730201900194 1 DRIVE SHAFT(F) .驱动轴(F) 1
113 730201900195 1 DRIVE SHAFT(R) .驱动轴(R) 1
114 730201900196 1 SPLINES JOINT .花键接头1
123 730201900197 1 ROILER BEARING .圆柱滚柱轴承2
124 730201900198 1 NEEDLE BEARING .滚针轴承2
127 730201900199 1 BEARING WASHER .轴承垫圈4
730201900189 1 CYLINDER UNIT .缸体组件(R) 1st
141 730201900200 1 CYLINDER BODY ..缸体1
313 730201900213 1 OIL DISTRIBUTING PAN ..配油盘® 1 B
14 730201900190 1 CYLINDER UNIT .缸体组件(L) 1St
141 730201900200 1 CYLINDER BODY ..缸体1 B
314 730201900214 1 OIL DISTRIBUTING PAN ..配油盘(L) 1 B
730201900188 1 PISTON ASSY. .柱塞组件2
151 730201900201 1 PISTON ..柱塞18 B
152 730201900202 1 SLIPPER ..滑靴18 B
153 730201900203 1 PRESS PLATE .压板2
156 730201900204 1 SPHERE BUSH .球面衬套2
157 730201900205 1 BACKWARD SPRING .回程弹簧18
211 730201900206 1 SLIPPER PAN .滑靴盘2
730201900191 1 Assembly，swashplate .斜盘组件2st
212 730201900207 1 Plate，swash ..斜盘2 B
214 730201900208 1 LEANING BUSH ..倾斜衬套2 B
251 730201900209 1 Support，swashplate .斜盘支撑台2
261 730201900210 1 OIL SEAL COVER .油封盖(F) 1
271 730201900211 1 PUMP BODY .泵体2
312 730201900212 1 OIL DISTRIBUTING SHELL .配油壳体1
401 751106000053 1 INNER HEXAGON BOLT .内六角螺栓8
406 751106000054 1 INNER HEXAGON BOLT .内六角螺栓4
466 730201900215 1 OIL PLUNGER .油塞3
468 730201900216 1 OIL PLUNGER .油塞4
490 730201900217 1 SINK PIN .沉栓21
532 730201900220 1 SERVO PISTON .伺服柱塞2

534 730201900221 1 BUMPING POST (L) .挡柱(L) 2
535 730201900222 1 BUMPING POST (S) .挡柱(S) 2
730201900193 1 ONE-WAY VALVE UNIT .单向阀2组件2st
541 730201900223 1 VALVE SEAT ..阀座1 B
544 730201900225 1 BUMPING POST 2 ..挡柱2 1 B
545 730201900226 1 STEEL BALL .钢球1
530 730201900218 1 LEANING PIN UNIT .倾斜销组件2st
531 730201900219 1 LEANING PIN ..倾斜销2 B
548 730201900227 1 BACKFEED PIN ..反馈销2 B
730201900192 1 ONE-WAY VALVE UNIT .单向阀1组件2st
543 730201900224 1 BUMPING POST 1 ..挡柱1 1 B
544 730201900225 1 BUMPING POST 2 ..挡柱2 1 B
545 730201900226 1 STEEL BALL ..钢球1 B
702 730603000691 1 O RING .O形密封圈2
710 730603000238 1 O RING .O形密封圈2
717 730603000280 1 O RING .O形密封圈4
724 730603000212 1 O RING .O形密封圈16
725 730603000211 1 O RING .O形密封圈4
728 730603000210 1 O RING .O形密封圈3
732 730603000227 1 O RING .O形密封圈2
774 730653000112 1 OIL SEAL .油封1
789 730654000256 1 BACK-UP RING .挡圈2
792 730654000257 1 BACK-UP RING .挡圈2
806 751103000087 1 HEXAGON NUT .六角螺母2
808 751103000088 1 HEXAGON NUT .六角螺母2
824 730250900600 1 RetainingRING .弹性挡环2
885 730201900228 1 OIL DISTRIBUTING PAN PIN .配油盘销2
886 730201900229 1 SPRING PIN .弹簧销4
901 751106000055 1 EYE BOLT .吊环螺栓2
953 751104000049 1 Screw，set .内六角定位螺钉2
954 751105000013 1 SET SCREW .定位螺钉2
981 730201900230 1 NAME PLATE .铭牌1
983 751105000014 1 RIVET .

POS COD VER QTY SUIT NUM INT SC
730201000127 1 MAIN PUMP ◎主泵1
730201900456 1 CONTROL INSTITUTION ASSY. 控制机构总成2
412 751104000053 1 INNER HEXAGON SCREW .内六角有孔螺钉2
413 751104000052 1 INNER HEXAGON SCREW .内六角有孔螺钉2
436 751104000051 1 INNER HEXAGON SCREW .内六角有孔螺钉2
438 751104000050 1 INNER HEXAGON SCREW .内六角有孔螺钉10
496 730201900217 1 SUNK BOLT .沉栓5
601 730201900310 1 SHELL .壳体1 B
611 730201900309 1 BACK COUPLING BAR .反馈杆块1 B
612 730201900308 1 LEVER 1 .杠杆(1) 1 B
613 730201900307 1 LEVER 2 .杠杆(2) 1 B
614 730201900306 1 PIVOT POINT PIN .支点销1 B
615 730201900305 1 COMPENSATION PISTON .补偿活塞1 B
621 730201900304 1 INTRACAVITY STOPCOCK .腔内活栓1 B
622 730201900303 1 PISTON SHELL .活塞壳1 B
623 730201900455 1 COMPENSATION .补偿件1 B
624 730201900454 1 SPRING SEAT .弹簧座(C) 1 B
625 730201900300 1 OUTER SPRING .外弹簧1 B
626 730201900299 1 INNER SPRING .内弹簧1 B
627 730201900298 1 ADJUST RING .调整环(C) 1 B
628 751106000056 1 ADJUST BOLT .调整螺栓(C) 1 B
629 730201900297 1 COVER .盖了(C) 1 B
630 730201900296 1 LATCH NUT .锁紧螺母1 B
631 730201900295 1 GLIDING BLOCK .Pf滑块1 B
641 730201900294 1 GUIDE COVER .导向盖1 B
643 730201900453 1 GUIDE PISTON .导向活塞1 B
644 730201900452 1 SPRING SEAT .弹簧座(Q) 1 B
645 730201900291 1 ADJUST RING .调整环(Q) 1 B
646 730201900290 1 GUIDE SPRING .导向弹簧1 B
651 730201900289 1 GLIDING BLOCK .滑块1 B
652 730201900288 1 BUSH .衬套1 B
653 730201900287 1 SPRING SEAT 弹簧座1 B
654 730201900286 1 BACKWARD SPRING .回程弹簧1 B
655 730201900285 1 SPRING .弹簧1
656 730201900284 1 BLANKOFF PLATE .肓板1 B
708 730603000230 1 O RING .O形密封圈1
722 730603000229 1 O RING .O形密封圈3
724 730603000212 1 O RING .O形密封圈9
725 730603000710 1 O RING .O形密封圈1
728 730603000709 1 O RING .O形密封圈1
730 730603000226 1 O RING .O形密封圈1
732 730603000708 1 O RING .O形密封圈2
733 730603000224 1 O RING .O形密封圈1
734 730603000223 1 O RING .O形密封圈1
735 730603000707 1 O RING .O形密封圈1
753 730603000221 1 O RING .O形密封圈1
755 730603000211 1 O RING .O形密封圈2
756 730603000220 1 O RING .O形密封圈1
763 730603000219 1 O RING .O形密封圈1
801 751103000090 1 HEXAGON NUT .六角螺母2
802 751103000089 1 HEXAGON NUT .六角螺母1
814 730654000263 1 RETAINING RING .挡圈1
836 730654000262 1 RETAINING RING .挡圈1 B
858 730201900283 1 CLAMP RING .锁紧圈2
874 730201900282 1 PIN .销1 B
875 730201900281 1 PIN .销4 B
876 730201900280 1 PIN .销2 B
887 730201900279 1 PIN .销1 B
897 730201900278 1 PIN .销1 B
898 730201900277 1 PIN .销1 B
924 751105000015 1 INNER HEXAGON SET SCREW .内六角定位螺钉1
730201000127 1 MAIN PUMP ◎主泵1
730202000146 1 FORERUNNER PUMP 先导泵1
730201000207 1 .齿轮壳体组件1
307 730202900023 1 VALVE HANDLE ..阀杆1
308 730202900022 1 SEAT ..座1
35l 730202900019 1 GEAR WHEEL BOX ..齿轮箱1
353 730202900018 1 DRIVE GEAR WHEEL ..驱动齿轮1
354 730202900017 1 DRIVE GEAR WHEEL ..驱动齿轮1
887 730202900008 1 PIN ..销2
309 730202900021 1 SPRING SEAT .弹簧座1
310 730202900020 1 SPRING .弹簧1
311 751104000054 1 ADJUST SCREW .调整螺钉1
312 751103000091 1 LATCH NUT .锁紧螺母1
355 730202900016 1 FLITER CORE .滤芯1
361 730202900015 1 FRONT SHELL .前壳体1
433 730202900014 1 FLANGE .法兰2
434 730202900013 1 FLANGE .法兰2
435 730202900012 1 FLANGE .法兰4
466 730202900011 1 PLUG .塞1
700 730202900010 1 RING .环1
710 730603000238 1 O RING .0型圈1
725 730603000711 1 O RING .0型圈1
732 730603000708 1 O RING .0型圈1
850 730202900009 1 CLASP .卡环1
887 730201900278 1 PIN .销

POS COD VER QTY SUIT NUM INT SC
730201000127 1 PUMP ◎主泵1
730399900029 1 PROPORTIONAL VALVE ASSY. 比例阀块总成1
079 730399900028 1 ELECTROMAGNETISM PROPORTIONAL VALVE .电磁比例阀1
311 730399900025 1 VALVE CORE ..阀芯1
312 730399900024 1 VALVE COVER ..阀套1
324 730399900023 1 SPRING ..弹簧1
325 730399900022 1 C RING ..C型圈1 B
331 730399900021 1 SPRING SEAT ..弹簧座1
351 730399900020 1 AMORTIZATION PORE ..阻尼孔1
361 730603000283 1 O RING ..O型密封圈1
362 730603000282 1 O RING ..O型密封圈1
363 730603000281 1 O RING ..O型密封圈1
801 730399900019 1 MAGNET COIL ..电磁线圈1
901 730399900018 1 DATA PLATE ..铭牌1
326 730399900027 1 VALVE BLOCK .阀块1
407 751104000055 1 SCREW .螺钉3
466 730399900026 1 PLUG .堵头1
490 730201900217 1 SCREW .螺钉3
725 730603000211 1 O RING .O型密封圈4
732 730603000225 1 O RING .O型密封圈1
