Описание
НАСОС ГИДРАВЛИЧЕСКИЙ ГИДРОНАСОС НАСОСНАЯ УСТАНОВКА ГИДРОМОТОР МОТОР СТАНЦИЯ PUMP ДЛЯ ГУСЕНИЧНОГО ЭКСКАВАТОРА hydraulic main pump
1 60155077 Double Piston Pump Group 1 5-198
2 60153895 Leading Pump 1 5-202
3 60153897 Adjuster 2
4 60197254 Main Pump Repair Kit 1
5 61002283 Proportional Pressure Reducing Valve 2
60075452 Shaft(G) Drive 1
2 60006939 Bearing 2
3 60125196 Block Cylinder 2
4 60125205 Plunger Piston 18
5 60125190 Shoe 18
6 60075467 Pressure Plate 2
7 60015817 Spherical Bushing 2
8 60054345 Spring 18
9 60015757 Sliding Plate 2
10 60015821 Swash Plate 2
11 60075449 Bush Tilting 2
12 60064450 Swashplate Supporting Stage 2
13 60075480 Cover Seal 1
14 60125192 Pump Body 2
15 60075385 Valve Plate 1
16 60125201 Valve Plate (R) 1
17 60075438 Screw 4
18 60039400 Oil Plug 4
19 60008728 Set Screw 28
20 60008820 Plug 5
21 60075377 Stopper 2
22 60075376 Stopper 2
23 60008549 Pin 2
24 60150563 O-ring 1
25 60039422 O-ring 4
26 60075479 Oil Seal 1
27 60075424 Retaining Ring 2
28 60075423 Retaining Ring 2
29 60064417 Snap Ring,Sun Gear,No1 2
30 60008878 Pin 5
31 60075426 Lifting Ring 2
32 60075441 Screw Rod 2
33 60075453 Shaft(R) Drive 1
34 60075431 Coupling Spline 1
35 60006941 Front Bearing 2
33 60075453 Shaft(R) Drive 1
34 60075431 Coupling Spline 1
35 60006941 Front Bearing 2
36 60075476 Washer 3
37 60075469 Booster 1
38 60150552 Valve Plate 1
39 60125200 Valve Plate (L) 1
40 60075439 Screw 4
41 60039371 Hexagon Socket Head Cap Screw 4
42 60038654 Oil Plug 4
43 60075450 Angular Pin 2
44 60075455 Servo Plunger 2
45 60093160 O-ring 2
46 60125207 O-ring 1
47 60125209 O-ring 2
48 60075477 O-ring 3
49 60038716 O-ring 19
50 60038712 O-ring 6
51 60125208 O-ring 2
52 60039359 Nut 4
53 60075461 Pin 2
54 60075440 Screw Rod 2
55 60100511 Label 1
56 60038620 Pin 2
57 60331157 Servo Plunger Assembly 1
1 60008508 Stem, valve 1
2 60008493 Seat, valve 1
3 60008523 Retaining Ring 1
4 60008500 Spring 1
5 60008496 Adjusting Screw Rod 1
6 60008505 Nut 1
7 60075382 Cover 1
8 60075409 Gear 1
9 60075410 Gear 1
10 60008491 Filter 1
11 60075381 Cover 1
12 60081461 Screw 2
13 60081462 Screw 2
14 60081460 Screw 4
15 60008724 Plug 1
16 60008504 Washer 1
17 60008736 Pin 2
18 60008697 O-ring 1
19 60008701 O-ring 1
20 60075425 Washer 1
21 60125207 O-ring 1
