Описание
ГЛАВНЫЙ МАСЛЯНЫЙ PUMP ОСНОВНОЙ НАСОСНАЯ СТАНЦИЯ ГИДРАВЛИЧЕСКАЯ ГИДРОМОТОР МОТОР ГИДРАВЛИЧЕСКИЙ ДЛЯ ГУСЕНИЧНОГО ЭКСКАВАТОРА ХУНДАЙ ХЕНДАЙ
КОМПЛЕКТУЮЩИЕ НАСОСА
*-1 ZGBP-00870 . Pump Unit-Main 1
2 ZGBP-00871 .. Rotary Assy 1
2-1 ZGBP-00732 ... Rotary Kit 1
2-1-1 ZGBP-00735 .... Block-Rotary 1
2-1-3 ZGBP-00736 .... Pin-Center 1
2-1-4 ZGBP-00737 .... Piston-Rotary(1ea) 9
2-1-6 ZGBP-00738 .... Shim-Adjustment 1
2-1-7 ZGBP-00739 .... Spring-Compression 1
2-1-11 ZGBP-00740 .... Plate-Retaining 1
2-1-12 XJDD-00153 .... Screw 18
2-2 ZGBP-00733 ... Shaft-Drive 1
2-2-1 ZGBP-00748 .... Shaft-Drive 1
2-2-2 ZGBP-00749 .... Ring-Shim 1
2-2-3 ZGBP-00750 .... Disc-Supporting 1
2-2-4 ZGBP-00751 .... Ring-Retaining 1
2-2-5 ZGBP-00752 .... Bearing-Tapered Roller 1
2-2-6 ZGBP-00753 .... Bearing-Tapered Roller 1
2-4 ZGBP-00862 ... Lens-Control Rh 1
3 ZGBP-00872 .. Rotary Assy 1
3-1 ZGBP-00732 ... Rotary Kit 1
3-1-1 ZGBP-00735 .... Block-Rotary 1
3-1-3 ZGBP-00736 .... Pin-Center 1
3-1-4 ZGBP-00737 .... Piston-Rotary(1ea) 9
3-1-6 ZGBP-00738 .... Shim-Adjustment 1
3-1-7 ZGBP-00739 .... Spring-Compression 1
3-1-11 ZGBP-00740 .... Plate-Retaining 1
3-1-12 XJDD-00153 .... Screw 18
3-2 ZGBP-00766 ... Shaft-Drive 1
3-2-1 ZGBP-00768 .... Shaft-Drive 1
3-2-2 ZGBP-00749 .... Ring-Shim 1
3-2-3 ZGBP-00750 .... Disc-Supporting 1
3-2-4 ZGBP-00751 .... Ring-Retaining 1
3-2-5 ZGBP-00752 .... Bearing-Tapered Roller 1
3-2-6 ZGBP-00753 .... Bearing-Tapered Roller 1
3-4 ZGBP-00863 ... Lens-Control Lh 1
4 ZGBP-00723 .. Pump Assy-Hyd Gear 1
4-1 ZGBP-00769 ... Pump-Hyd Gear 1
4-2 ZGBP-00770 ... Screw-Socket Hd 2
5 ZGBP-00724 .. Housing-Pump 1
7 ZGBP-00864 .. Wheel-Toothed 1
8 ZGBP-00726 .. Shaft-Plug In 1
20 ZGAR-00402 .. Ring-Retainer 1
21 ZGBP-00727 .. Ring-Seal 1
22 ZGBP-00728 .. Ring-Shim 1
23 ZGAX-00144 .. Screw-Locking 1
24 ZGBP-00729 .. Plug-Screw 3
25 ZGBP-00730 .. Bearing-Roller 2
27 ZGBP-00731 .. Key-Parallel 1
